Position your products for success

GNSS boards for GPS, GLONASS, GALILEO, BeiDOU, and other constellations

Hero Image

Increase positioning accuracy while reducing development time

Save development time by using prebuilt GNSS receiver boards that feature Vanguard Technology™ with Universal Tracking Channels™ for reliable "all in view" tracking. These low-power consumption boards provide centimetre-level accuracy and sub-degree heading orientation for positioning applications.

Compare products

Find the right product for your applications.

B111A

B111A

Signals tracked

GPS: L1, L2, L2C
GLONASS: L1, L2, L2C
BeiDou: B1, B2
Galileo: E1
SBAS: L1
QZSS: L1, L2C

Positioning

RTK
PPP
DGNSS
Stand-alone

Heading

HD2, Azimuth filter

Update rate

Up to 100 Hz

Hot/cold start

< 15 sec / < 44 sec typical

Reacquisition

< 1 sec

Power consumption

3.4 VDC to 4.5 VDC / 1.3 W typical

Operating temperature

-40°C to +85°C

Vibration

4g Sine Vibe (SAEJ1211); 7.7g Random Vibe (MIL-STD 810F)

Dimensions

40 mm x 55 mm x 10 mm

Weight

< 20 g

B125

B125

Signals tracked

GPS: L1, L2, L2C, L5
GLONASS: L1, L2, L3
BeiDou: B1, B2
Galileo: E1, E5a, E5b, E5AltBOC
SBAS: L1
QZSS: L1, L2, L1C, L1-SAIF, L2C,
L5 L-band

Positioning

RTK
PPP
DGNSS
Stand-alone

Heading

HD2, Azimuth filter

Update rate

Up to 100 Hz

Hot/cold start

< 15 sec / < 44 sec typical

Reacquisition

< 1 sec

Power consumption

3.4 VDC to 5.5 VDC / 2.0 W typical

Operating temperature

-40°C to +85°C

Vibration

4g Sine Vibe (SAEJ1211); 7.7g Random Vibe (MIL-STD 810F)

Dimensions

55 mm x 40 mm x 10 mm

Weight

< 20 g

B210

B210

Signals tracked

GPS: L1, L2, L2C, L5
GLONASS: L1, L2, L3
BeiDou: B1, B2
Galileo: E1, E5a, E5b, E5AltBOC
SBAS: L1
QZSS: L1, L2, L1C, L1-SAIF, L2C, L5
L-band

Positioning

RTK
PPP
DGNSS
Stand-alone

Heading

VHD

Update rate

Up to 100 Hz

Hot/cold start

< 15 sec / < 44 sec typical

Reacquisition

< 1 sec

Power consumption

3.3 VDC to 4.5 VDC / 2.5 W typical

Operating temperature

-40°C to +85°C

Vibration

4g Sine Vibe (SAEJ1211); 7.7g Random Vibe (MIL-STD 810F)

Dimensions

60 mm x 100 mm x 12 mm

Weight
